How to effectively use the oil when using the reducer. The car needs gasoline to be able to run, and the same speed reducer, the speed reducer needs to use the oil to run. Every time you use the reducer, the oil will play a big role. Different speed reducers use different oils, and different temperatures make the difference in the oil used. So how do we use the oil to run our gearbox? The following small series will explain in detail the techniques and methods of using the oil in the reducer.
1. When refueling, you can turn on the ventilation cap on the upper part of the base to refuel. When draining oil, screw the oil drain plug on the lower part of the base to release the oil. The reducer is internally oil-free.
2, The newly issued reducer has been greased and replaced every six months. The grease is made of aluminum disulfide-2# or 2L-2# lithium base grease.
3, The horizontal cycloid reducer is lubricated under the normal conditions, and the oil level is kept at the middle of the oil window. When the working conditions are bad, the ambient temperature is at high temperature.
4. The oil should be replaced after 100 hours of refueling operation, and the internal oil should be cleaned and then work continuously. The 8-hour working system should be replaced every six months. If the working conditions are bad, the oil change time can be shortened properly. Cleaning and oil change play an important role in extending the life of the gear unit. Lubricating oil should be replenished frequently during use.
5, the vertical installation of the planetary cycloid reducer should strictly prevent the oil pump from breaking oil to avoid damage to the components of the reducer.
6. Cycloidal pinwheel reducer is generally lubricated with 40# or 50# mechanical oil at normal temperature. In order to improve the performance of the reducer and extend the service life of the cycloid reducer, it is recommended to use 70# or 90# extreme pressure gear. Oil, oil should also be reconsidered when working under high and low temperature conditions.
In summary, it can be analyzed that the oil plays a very important role in the operation of the entire reducer. Under the normal temperature, the performance of the reducer can be fully provided by using the oil. When working long-term and using the reducer, it can effectively protect the reducer and extend the service life of the reducer.
